Engine body




Power supply voltage

AC 110 ~ 240 V



Frequency

50/60 Hz



Power consumption

100 VA



Max. Coolant flow rate

100 ml/min



Fuse

2 x 250 V - T1.25 AH



Dimension

250mm(W) x 250mm(L) x 110mm(H)










Motor




Model

ISM-B70L



Max. Speed

40,000 rpm



Internal resistance(Phase to phase)

730 [mΩ]



Internal inductance(Phase to phase)

110 [uH]



Fuse

24mm(Diameter) x 100mm(Length)



Weight

80 g



Optic

Yes










Foot pedal




Model

FC-V1



Speed control

Variable



Foot control functions

Program control, Coolant control, Forward/Reverse
